Allure

Allure

Pivot Shower Door

Allure
Allure
Allure
Allure
Allure

PRODUCT SPECIFICATION

  • 3/8 in. (10 mm) thick clear tempered glass
  • Chrome hardware finish
  • Frameless glass design
  • 1 in. out-of-plumb adjustment within each wall profile
  • 5 in. width adjustment in pivot hardware (7 in. total)
  • Pivot shower door. Anodized aluminum wall profiles
  • Unique adjustable pivot door hardware
  • Reversible for right or left door opening installation
  • Finished walls required for measurement and installation
  • Material: Tempered Glass, Aluminum, Brass
  • Tempered glass ANSI certified
  • Optional SlimLine shower base and shower backwalls sold separately

    • Note: To minimize leakage, install shower head opposite of door opening aimed at tiled walls, fixed shower panel or floor

  • Limited lifetime manufacturer warranty


    • NOTE: DreamLine Shower Door dimensions are for finished opening measurements (finished/tiled walls), while DreamLine SlimLine Shower Base dimensions are provided for rough opening measurements (against the studs)

    NOTE: DreamLine Shower Bases will always be larger (approximately 2 in.) than the corresponding DreamLine Shower Door. Please, take this information under advisement when ordering your Shower Base and Shower Door separately

    Professional installation recommended

The Allure pivot shower door will give any bathroom a fresh perspective with clean lines and a flexible installation. A frameless design and premium 3/8 in. thick tempered glass deliver the look and feel of custom glass at an excellent value.

Model Number Width Range Fits Opening Width
SHDR-4230728-01 30" - 31" 30" - 37"
SHDR-4231728-01 31" - 32"
SHDR-4232728-01 32" - 33"
SHDR-4233728-01 33" - 34"
SHDR-4234728-01 34" - 35"
SHDR-4235728-01 35" - 36"
SHDR-4236728-01 36" - 37" 36" - 43"
SHDR-4237728-01 37" - 38"
SHDR-4238728-01 38" - 39"
SHDR-4239728-01 39" - 40"
SHDR-4240728-01 40" - 41"
SHDR-4241728-01 41" - 42"
SHDR-4242728-01 42" - 43" 42" - 49"
SHDR-4243728-01 43" - 44"
SHDR-4244728-01 44" - 45"
SHDR-4245728-01 45" - 46"
SHDR-4246728-01 46" - 47"
SHDR-4247728-01 47" - 48"
SHDR-4248728-01 48" - 49" 48" - 55"
SHDR-4249728-01 49" - 50"
SHDR-4250728-01 50" - 51"
SHDR-4251728-01 51" - 52"
SHDR-4252728-01 52" - 53"
SHDR-4253728-01 53" - 54"
SHDR-4254728-01 54" - 55" 54" - 61"
SHDR-4255728-01 55" - 56"
SHDR-4256728-01 56" - 57"
SHDR-4257728-01 57" - 58"
SHDR-4258728-01 58" - 59"
SHDR-4259728-01 59" - 60"
SHDR-4260728-01 60" - 61" 60" - 67"
SHDR-4261728-01 61" - 62"
SHDR-4262728-01 62" - 63"
SHDR-4263728-01 63" - 64"
SHDR-4264728-01 64" - 65"
SHDR-4265728-01 65" - 66"
SHDR-4266728-01 66" - 67"
