Infinity-Z
Shower Door, Base & Backwalls
PRODUCT SPECIFICATION
-
Items included: Infinity-Z Shower Door, Single Threshold Shower Base and QWALL-5 Shower Backwall Kit
- 1/4 in. (6 mm) clear or frosted tempered glass
- Chrome or Brushed Nickel hardware finish
- Frameless glass design
- Out-of-plumb installation adjustability: Up to 1 in. per side
- Anodized aluminum profiles and guide rails
- Convenient towel bar on the outside panel
- Reversible for right or left door opening installation
- Material: Tempered Glass, Aluminum
- Tempered glass ANSI certified
- Color: White
- High quality scratch and stain resistant acrylic
- Slip-resistant textured floor for safe showering
- Integrated tile flange for easy installation and waterproofing
- Fiberglass reinforcement for durability
- cUPC certified
- Drain not included
- Center, right, left drain configurations
- Color: White
- Assembly required
- Designed to be installed over existing finished surface (not directly against studs)
- Includes 2 glass corner shelves
- Attractive tile pattern
- Unique water tight connection of panels
- Durable acrylic/ABS construction
- Trim-to-Size sidewall design
- Must be trimmed during installation
- Limited lifetime manufacturer warranty
- Shower Backwalls: Limited 1 (one) year manufacturer warranty
Infinity-Z Shower Door:
Single Threshold Shower Base:
QWALL-5 Shower Backwall Kit:
Product Warranty:
This kit combines the INFINITY-Z™ shower door, universal shower backwall panels and a coordinating SlimLine™ shower base to completely transform a shower space. The INFINITY-Z sliding shower door is matched with a stationary glass panel to provide a wide bath entry. The stationary panel is fitted with a convenient towel bar that doubles as a handle. The SlimLine shower base incorporates a low profile design for a sleek modern look, while the shower backwall panels have a tile pattern. This smart kit offers the perfect solution for a bathroom remodel or tub-to-shower conversion project.
for individual technical drawing| Kit Model Number |
Kit Size, in. D x W x H* |
Items Included | |||
| Base | Base Configuration | Backwalls | Door | ||
| DL-6107C | 36 x 48 x 76-3/4 | DLT-1136480 | Center Drain | SHBW-1450743-01 | SHDR-0948720 |
| DL-6116C | 30 x 60 x 76-3/4 | DLT-1130600 | Center Drain | SHBW-1462743-01 | SHDR-0960720 |
| DL-6116L | DLT-1130601 | Left Hand drain | |||
| DL-6116R | DLT-1130602 | Right Hand drain | |||
| DL-6117C | 32 x 60 x 76-3/4 | DLT-1132600 | Center Drain | ||
| DL-6117L | DLT-1132601 | Left Hand drain | |||
| DL-6117R | DLT-1132602 | Right Hand drain | |||
| DL-6118C | 34 x 60 x 76-3/4 | DLT-1134600 | Center Drain | ||
| DL-6118L | DLT-1134601 | Left Hand drain | |||
| DL-6118R | DLT-1134602 | Right Hand drain | |||
| DL-6119C | 36 x 60 x 76-3/4 | DLT-1136600 | Center Drain | ||
| DL-6119L | DLT-1136601 | Left Hand drain | |||
| DL-6119R | DLT-1136602 | Right Hand drain | |||
